Decade Resistance Unit
Product Code : EL-EE-10902
Quick Answer: The Decade Resistance Unit provides resistance up to 9999 ohms with ±1.0% tolerance, using series-connected decades of high stability metal film elements, each switched from 0 to 9.
Last updated: October 2026
Key Features
- High stability metal film resistance elements
- Series-connected decades, each switched from 0 to 9
- Range of 9999 ohms with ±1.0% tolerance
- 4 mm socket terminals linked to the ends of the chain
- Resistance value marked on the top panel
- Suitable for a.c. or d.c. use
Technical Specifications
| Specification | Value |
|---|---|
| Range | 9999 ohms |
| Tolerance | ±1.0% |
| Elements | High stability metal film |
| Decade switching | 0 to 9 per decade |
| Terminals | 4 mm socket terminals |
| Dimensions | 220 mm x 110 mm x 60 mm |
About This Product
The unit is intended for use as a potential divider, a ratio arm and similar purposes. Its decades are connected in series and mounted in line, each switch set between 0 and 9, with the 4 mm terminals at the ends of the chain. The top panel shows the resistance value. The Decade Resistance Unit is available for supply within India and for export to South Korea, Lithuania, Sri Lanka, Bhutan and Lesotho.
Frequently Asked Questions
Q1. Can the unit be used with alternating current?
Yes. It is equally suitable for a.c. or d.c. use.
Related: Electricity & Electromagnetism, Decade Capacitance Box, Component Investigations Board.
For a quotation on the Decade Resistance Unit, contact School Equipments India.
